Powerblock 12.8V Lithium Battery
  • Powerblock 12.8V Lithium Battery

Powerblock 12.8V Lithium Battery

Smaller Volume/Higher Efficiency/Higher Energy Density/Simple Installation Method. Poweblock series products can charge and discharge 1500 cycles efficiently to achieve stable energy output under high load.

Send Inquiry

Product Description

Smaller Volume/Higher Efficiency/Higher Energy Density/Simple Installation Method.

Poweblock series products can charge and discharge 1500 cycles efficiently to achieve stable energy output under high load.



Battery Parameters
Nominal Voltage 12.8V
Cell Capacity 100Ah/150Ah/200Ah/300Ah
Nominal Energy 1280Wh/1920Wh/2560Wh/3840Wh
Discharge Voltage 10V
Charge Voltage 14.4V
Cont. Charge Current 100A/150A
Max. Charge Current 100A/150A
Cont. Discharge Current 150A/200A
Max.Discharge Current 150A/200A
Cont. Discharge DC Power 1280W/1920W
Max.Discharge DC Power 1280W/1920W/2560W
Operating Temperature

0℃ ~ 45℃(Charge)

-20℃ ~ 55℃(Discharge)



General Data
Scalability Communication, bluetooth, heating, display
DOD 100%
Communication NON
Cycle Life 1500cycles 0.5c 80% 100%DOD 25°C
IP Grade IP65
Installation Same as lead-acid battery
Dimension 328*172*230mm/328*172*230mm/ 483*170*240mm/520*240*222mm
Weight 11KG/14KG/21KG/29KG
Warranty One Year



UN38.3, IEC62619, CE

When the temperature < 0°C or > 45°C, the product performance is limited.
