Half-cell High Efficiency Mono Solar Panels
CI New Energy manufactures Non-standard Mono Solar Panels in the 400—600W Power Range. Advanced technology ensures High Quality for superior performance.
Send Inquiry
Product Description
High Efficiency Mono Solar Panels
Half-cell High Efficiency Mono Solar Panels use advanced technology to provide half-cell monocrystalline solar panels with high-efficiency characteristics. Optimized design reduces energy loss, improves power generation efficiency, and is suitable for various environmental conditions. Superior performance and reliability make it the solar solution of choice.
Key Features:
LINEAR PERFORMANCE WARRANTY
- 12 years minimum 92% power output
- 25 years minimum 84.8% power output
- 10 years Product warranty on materials and workmanship
Specification
|
Cell Type |
Maximum Power(Pmax) |
Maximum Power(Pmax) |
Maximum Power Current(Imp) |
Open-circuit Voltage(Voc) |
Short-circuit Current(Isc) |
Weight |
Dimension |
Module Efficiency |
| 600W | 46.64V | 12.86A | 54.67V | 13.62A | 30kg | 2464x1134x35mm | 21.50% | |
| 182mm | 550W | 41.97V | 13.11A | 49.95V | 14.05A | 28.5kg | 2279x1134x35mm | 21.30% |
| 540W | 41.62V | 12.98A | 49.55V | 13.89A | 28.5kg | 2279x1134x35mm | 21.10% | |
| 500W | 38.33V | 13.05A | 45.65V | 13.92A | 26.2kg | 2094x1134x35mm | 21.10% | |
| 460W | 34.67V | 12.98A | 41.25V | 13.89A | 23.9kg | 1909x1134x30mm | 21.20% | |
| 400W | 36.96V | 13.06A | 36.96V | 13.82A | 20.9kg | 1722x1134x30mm | 20.50% | |
| 166mm | 400W | 34.2V | 11.7A | 41.5V | 12.3A | 20kg | 1755x1038x30mm | 21.96% |
| 450W | 41.6V | 10.81A | 48.9V | 11.46A | 24kg | 2094x1038x35mm | 20.70% |
